Cooler Master MCB-CM694-KG5N-S00 MasterBox CM694 Tempered Glass Black Steel ATX Mid Tower Desktop Chassis 128 $
Click to enlarge

Cooler Master MasterBox MB511 ATX Mid-Tower with Front Mesh Ventilation, Front Side Red Accent Mesh Intake & Transparent Acrylic Side Panel , Black

ATX Mid-Tower Front Mesh Ventilation Black

Brand Cooler Master
Case Type Mid Tower
Recommended Uses For Product Gaming
Color Black
Material Alloy Steel, Plastic
Power Supply Mounting Type Bottom Mount
Cooling Method Fan
Item Weight 14.2 Pounds
Number of USB 2 Ports 2
Total USB Ports 2

Expert Features

  • Mesh front panel – offers efficient airflow for demanding systems from the mesh front panel
  • Aggressive intakes large intakes on each side of the front panel Pay tribute to high Performance Cars
  • Edge to edge transparent side panel showcase your build through the transparent side panel expert zone
  • Cooling support Support for a total of six 120mm fans, and front, top and rear radiator placement ensures that you don’t have to compromise on performance
  • Graphics Card support up to 400mm You won’t ever have to worry about the fit of your graphics card with support for even the largest, widest cards





Mesh Front Panel

MESH FRONT PANEL

The fine mesh front panel filters dust while offering efficient airflow for demanding systems.

Excellent Thermal Performance

EXCELLENT THERMAL PERFORMANCE

Optimized airflow due to the semi-meshed front panel and ventilation holes on top of the case.

Fan And Radiator Support

FAN AND RADIATOR SUPPORT

Front: Three 120mm or two 140mm* fans and up to a 360mm radiator with a maximum thickness of 50mm without fans.
Top: Two 120mm or two 140mm fans and supports a 120mm or a 240mm radiator.
Rear: One 120mm fan or radiator. All to ensure you don’t have to compromise on performance.

* 2 x 140mm fans in front can only be mounted behind the front plate

Edge-to-edge Transparent Side Panel

EDGE-TO-EDGE TRANSPARENT SIDE PANEL

Showcase your build through the transparent side panel.

ATX
MICRO-ATX
MINI-ITX

EXPANDING THE POSSIBILITIES

The spacious interior fits all standard motherboards for your gaming needs.

ATX
MICRO-ATX
MINI-ITX
Main Components Clearance

MAIN COMPONENTS CLEARANCE

The MB511 case supports CPU Coolers up to a height of 165mm, Graphic cards up to a length of 410mm and Power Supplies up to a length of 180mm.

Scenario

EXPERT SPECIFICATIONS

Model Number MCB-B511D-KANN-S00 (Red), MCB-B511D-KANN-S01 (Black), MCB-B511D-KANN-S02 (White), MCB-B511D-KANN-S03 (Blue)
Color(s) Black, *partial region on front panel: red/black/white/blue
Materials Steel, Plastic
Dimensions (L x W x H) expert zone
Motherboard Support ATX, Micro ATX, Mini ITX
Expansion Slots 7
5.25″ Drive Bays N/A
2.5″ / 3.5″ Drive Bays (Combo) 2
2.5″ Drive Bays 5 (Max.6)
I/O Panel 2x USB 3.0, Audio In & Out (Supports HD Audio)
Pre-installed Fans – Rear 1x 120mm
Fan Support – Top 2x 120mm, 2x 140mm
Fan Support – Front 3x 120mm, 2x 140mm
Fan Support – Rear 1x 120mm
Liquid Cooling Support – Front 120mm, 140mm, 240mm, 280mm, 360mm
Liquid Cooling Support – Top 120mm, 240mm
Liquid Cooling Support – Rear 120mm
Clearance – CPU Cooler 165mm/6.49″
Clearance – PSU 180mm/7.08″
Clearance – GFX 410mm/16.1″
Cable Routing – Behind Motherboard Tray 19mm / 0.74″expert zone
Dust Filters Front, Top, Bottom
Power Supply Support Bottom Mount, ATX
Series MasterBox Series
Size Mid Tower
SKU: MCB-B511D-KANN-S00

64 $

Compare
Add to wishlist
20 People watching this product now!

Description

ATX Mid-Tower Front Mesh Ventilation Black

Cooler Master MasterBox MB511 ATX Mid-Tower with Front Mesh Ventilation, Front Side Red Accent Mesh Intake & Transparent Acrylic Side Panel , Black

Customer Reviews
