CPU Socket Type
|
LGA 1700 |
Core Name
|
Raptor Lake |
# of Cores
|
20-Core (8P+12E) |
# of Threads
|
28-Threads |
Operating Frequency
|
- Performance-core Base Frequency: 3.4 GHz
- Efficient-core Base Frequency: 2.5 GHz
|
Max Turbo Frequency
|
- Intel Turbo Boost Max Technology 3.0 Frequency: Up to 5.6 GHz
- P-core Max Turbo Frequency: Up to 5.5 GHz
- E-core Max Turbo Frequency: Up to 4.3 GHz
|
L2 Cache
|
28MB |
L3 Cache
|
33MB |
Manufacturing Tech
|
Intel 7 |
64-Bit Support
|
Yes |
Hyper-Threading Support
|
Yes |
Memory Types
|
DDR4 3200 / DDR5 5600 |
Memory Channel
|
2 |
Max Memory Size
|
192 GB |
Max Memory Bandwidth
|
89.6 GB/s |
Virtualization Technology Support
|
Yes |
Integrated Graphics
|
None Integrated Graphics |
Scalability
|
1S Only |
PCI Express Revision
|
5.0 / 4.0 |
PCI Express Configurations
|
Up to 1×16+4, 2×8+4 |
Max Number of PCI Express Lanes
|
20 |
Thermal Design Power
|
125W |
Max Turbo Power
|
253W |
Cooling Device
|
Cooling device not included – Processor Only |
Compatible Desktop Chipsets
|
Intel H610 / Intel H670 / Intel B660 / Intel Q670 / Intel W680 / Intel Z690 / Intel H770 / Intel B760 / Intel Z790
* BIOS update may be required when used with some old chipset motherboard |
Operating System Supported
|
Linux / Windows 10 (22H2, 21H2) / Windows 11 (22H2, 21H2) |
Advanced Technologies
|
- Intel Gaussian & Neural Accelerator: 3.0
- Intel Thread Director
- Intel Deep Learning Boost (Intel DL Boost) on CPU
- Intel Speed Shift Technology
- Intel Turbo Boost Max Technology 3.0
- Intel Turbo Boost Technology: 2.0
- Intel Hyper-Threading Technology
- Intel 64
- Instruction Set: 64-bit
- Instruction Set Extensions: Intel SSE4.1, Intel SSE4.2, Intel AVX2
- Idle States
- Enhanced Intel SpeedStep Technology
- Thermal Monitoring Technologies
- Intel Volume Management Device (VMD)
|
Security & Reliability
|
- Intel Standard Manageability (ISM)
- Intel Control-Flow Enforcement Technology
- Intel AES New Instructions
- Secure Key
- Intel OS Guard
- Execute Disable Bit
- Intel Boot Guard
- Mode-based Execute Control (MBEC)
- Intel Virtualization Technology (VT-x)
- Intel Virtualization Technology for Directed I/O (VT-d)
- Intel VT-x with Extended Page Tables (EPT)
|
